This 30,000 sq ft commercial façade upgrade project involved LOD 400 BIM modeling to update wall cladding and material finishes. Using Autodesk Revit and Navisworks, Techture incorporated client markups and revised material schedules directly into the coordinated model. The updated layouts and finish swaps were validated against existing building geometry, ensuring accuracy and constructability.
1. LOD 400 BIM modeling of wall cladding panels and finish systems based on revised client markups.
2. Incorporation of updated material specifications and finish schedules into the coordinated model.
3. Extraction of fabrication-ready shop drawings and material quantity reports.
4. Clash checks and interface coordination between cladding layers, substrates, and existing structural surfaces.
